Active GPS Antenna - Feed through or DGO
Applications
- AUVs
- ROVs
- Drifters
- Profiling floats
- Manned submersibles
- Location & recovery
- Datasheet
Features
- Pressure rated to 6,000 m
- Active GPS antenna element
- Rapid position acquisition at the sea-surface
- Small, light-weight, low drag
DGO or Subconn Connector
- Allows antenna to be mounted independently of electronics
- Straight or right-angled cable assemblies available
Feed-through Connection
- For antenna mounting directly onto pressure housing
Specification
|
Type |
Quadrifilar Helix |
| Frequency |
1573.42-1577.42 MHz |
| Polarization |
Right-hand circular |
| Voltage |
2.8 to 3.6 V |
| Current |
13 mA |
| Gain |
+24 dBic |
| Beamwidth |
135 Degrees |
| Bandwidth |
20 MHz |
| Axial Ratio |
<2.0 @Zenith |
| VSWR |
<2.0:1 |
| Impedance |
50 |
| Temperature |
-40 to +85 °C |
